SRT BH6022 HV (0.06s/22.0kg/8.4V) Brushless Servo View larger
    SRT BH6022 HV (0.06s/22.0kg/8.4V) Brushless Servo
    SRT BH6022 HV (0.06s/22.0kg/8.4V) Brushless ServoSRT BH6022 HV (0.06s/22.0kg/8.4V) Brushless ServoSRT BH6022 HV (0.06s/22.0kg/8.4V) Brushless Servo

SRT BH6022 HV (0.06s/22.0kg/8.4V) Brushless Servo

Buy SRT BH6022 HV (0.06s/22.0kg/8.4V) Brushless Servo, Model BH6022 online. New Arrivals,Servo & receivers,SRT Servo,SERVO & RECEIVERS,Σερβομηχανισμοί - Servo

$93.33

SAVE 50%-80% OFF

$65.33

- +

Add to wishlist

Frasers Plus

$0 today, followed by 3 monthly payments of $3, interest free. Read More

SRT BH6022 HV (0.06s/22.0kg/8.4V) Brushless Servo

The latest generation of SRT  servos provides you with the performance you need for any scale vehicle\ Air Plane\Boat\Robot application. are standard size servos for High-Voltage applications up to 8.4V, feature all metal case construction for the ultimate performance.
All of SRT servos  are available to be customized for easy installation by OEM order.

Features:
  • Ideal for 1/10 on road applications
  • Incredible efficiency and low power consumption
  • Aluminum case for good heat dissipation
  • NMB dual main bearings
  • 25T output shaft
  • 1-Year Limited Warranty
Specifications:
Type Digital
Bearing Dual
Motor Type Brushless
Gear Type Metal
Gear Material Titanium & Alu
Control System Pulse width control
Working Frequence 1520μs / 330hz
Operating Voltage dc6.0-8.4V
Operating Temperature Range -10 to + 60 degree
Operating Speed (6.0V) 0.088 sec/60 degrees at no load
Operating Speed (7.4V) 0.068 sec/60 degrees at no load
Operating Speed (8.4V) 0.06 sec/60 degrees at no load
Stall Torque (6.0V) 17.0kg.cm (236.1 oz/in)
Stall Torque (7.4V) 19.0kg.cm (263.9 oz/in)
Stall Torque (8.4V) 22.0kg.cm (305.5 oz/in)
Potentiometer Drive Direct drive
Dimensions 41.3x20.5x38.3 mm /1.63x0.80x1.51 in
Weight 69.0g (2.43 oz)
Connector Wire Length jr 300mm

Description

Product code: SRT BH6022 HV (0.06s/22.0kg/8.4V) Brushless Servo
