Home / Outlet/ Brands/ SRT BH922S (0.055s/22.0kg/8.4V) Brushless Servo
SRT BH922S (0.055s/22.0kg/8.4V) Brushless Servo View larger
    SRT BH922S (0.055s/22.0kg/8.4V) Brushless Servo
    SRT BH922S (0.055s/22.0kg/8.4V) Brushless ServoSRT BH922S (0.055s/22.0kg/8.4V) Brushless ServoSRT BH922S (0.055s/22.0kg/8.4V) Brushless Servo

SRT BH922S (0.055s/22.0kg/8.4V) Brushless Servo

Buy SRT BH922S (0.055s/22.0kg/8.4V) Brushless Servo, Model BH922S online. New Arrivals,Servo & receivers,SRT Servo,SERVO & RECEIVERS,Σερβομηχανισμοί - Servo

$135.28

SAVE 50%-80% OFF

$94.70

- +

Add to wishlist

Frasers Plus

$0 today, followed by 3 monthly payments of $3, interest free. Read More

SRT BH922S (0.055s/22.0kg/8.4V) Brushless Servo

Features:
  • Ideal for 1/10 on road and 1/8 off road scale applications
  • Superior Holding Speed
  • Incredible efficiency and low power consumption
  • Standard dimension make it perfect for vehicles that can benefit from a high quality servo
  • CNC Machined aluminum case for exceptional cooling
  • NMB dual main bearings
  • SSR mode compatible
  • 25T output shaft
  • HD 4096 Resolution
  • 2 μsec Dead Band
Item no 6.0V 7.4V 8.4V Gear Motor Case Dimension
(mm)		 Weight
(g)
Speed:
sec/60°		 Torque:
kg-cm/oz-in		 Speed:
sec/60°		 Torque:
kg-cm/oz-in		 Speed:
sec/60°		 Torque:
kg-cm/oz-in
BH922S 0.08 17.0/236.1 0.06 20.0/277.7 0.055 22.0/305.5 Titanium & Steel Brushless CNC 40.0*20.0*38.0 70.0
Specifications:
  • type: Digital
  • bearing: Dual
  • motor Type: Brushless
  • gear Type: Metal
  • gear Material: Titanium & Steel
  • control system: pulse width control
  • working frequence: 1520μs / 330hz
  • operating voltage: dc 6.0-8.4v
  • operating temperature range: -10 to + 60 degree
  • operating speed (6.0v): 0.08 sec/60 degrees at no load
  • operating speed (7.4v): 0.06 sec/60 degrees at no load
  • operating speed (8.4v): 0.055 sec/60 degrees at no load
  • stall torque (6.0v): 17.0kg.cm (236.1 oz/in)
  • stall torque (7.4v): 20.0kg.cm (277.7 oz/in)
  • stall torque (8.4v): 22.0kg.cm (305.5 oz/in)
  • potentiometer drive: direct drive
  • dimensions: 40x20x38.0 mm /1.57x0.79x1.49 in
  • weight: 70.0g (2.47 oz)
  • connector wire length: jr 250 mm

Description

Product code: SRT BH922S (0.055s/22.0kg/8.4V) Brushless Servo
